A Typical Path Network

The following diagram shows a path network consisting of seven nodes (N1 to N7) connected by path segments. Path segments may be straight lines from one node to another, as in the segment from node N7 to node N6, or they can have any number of joints, such as the segment from node N2 to node N5.
